Professional Veterinary Handheld Vital Sign Monitor

V100 Professional Veterinary Handheld Vital Sign Monitor. The smallest and exquisite handheld vital sign monitor worldwide.

Product Description

Features

1.The smallest and exquisite handheld vital sign monitor worldwide.
2.Accurate measurement in 0.05% Low perfusion Index, the word leading production in the movement environment.
3.Provide the parameter of PI (Perfusion Index 0.05%-20%).
4.Suitable for all kinds of animals.
5.Easy operation by 3.5’’ color TFT.
6.Multiple vital signs measurement parameters for collocation are optional. (NIBP, Spo2, Temp) (NIBP, Temp) (Spo2, Temp).
7.Up to 100 users ID switch.
8.Two measurements mode: Spot and Monitoring.
9.NIBP adopts SAWAA (Self-Adaptive-Waveform-Amplitude–Adjust) algorithm and SAFD (Self-Adaptive-Fast-Deflation) algorithm.
10.Data storage capabilities, support for historical data view, and trend chart back to see.
11.Under monitoring mode, can continuously record 48 hours of measurement data.
12.Under spot mode, 100 users ID, each user can store 200sets data.
13.Support audio and visual alarm, support to set alarm upper and lower limit values.

Professional Veterinary Handheld Vital Sign Monitor

professional veterinary handheld vital sign monitor5

Lithium-ion battery power supply

Power Type: Lithium-ion battery
Operation time: 8 hours for normal operation
Temperature: Operating: 0℃~45℃
Starage/Transportation: -20℃~65℃
Humidity: Operating: 15% to 90% noncondensing
Storage: 10% to 95% noncondensing
Operating Altitude: Up to 5000 meters
Dimension: 146mm*67mm*30mm Weight 250g

1.The smallest and exquisite handheld vital sign monitor in the worldwide. 2.Accurate measurement in 0.05% Low perfusion Index,the word leading production in the movement environment 3.Provide the parameter of PI( Perfusion Index 0.05%-20%) 4.Suitable for all kinds of animals 5.Easy operation by 3.5’’ color TFT 6.Multiple vital signs measurement parameters for collocation optional NIBP、Spo2、Temp NIBP、Temp Spo2、Temp 7.Up to 100 users ID switch 8.Two measurements mode:Spot、Monitoring 9.NIBP adopt SAWAA(Self-Adaptive-Waveform-Amplitude –Adjust)algorithm and SAFD(Self-Adaptive-Fast-Deflation)algorithm 10.Data storage capabilities, support for historical data view and trend chart back to see Under monitoring mode, can continuously record 48 hours of measurement data Under spot mode,100 users ID, each user can store 200sets data 11.Support audio and visual alarm,support to set alarm upper and lower limit values 12.Lithium ion battery power supply 13.Power Type: Lithium ion battery 14.Operation time: 8 hours for normal operation 15.Temperature: Operating: 0℃~45℃ 16.Starage/ Transportation: -20℃~65℃ 17.Humidity: Operating: 15% to 90% noncondensing 18.Storage: 10% to 95% noncondensing 19.Operating Altitude: Up to 5000 meters 20.Dimension :146mm*67mm*30mm Weight 250g Optional Charging dock3

Technical Specifications

Display: 3.5’’ color TFT, Resolution: 320*480
Indicator: Alarm indicator, Power indicator
Alarm: Probe off, low power
Alarm Type: Visual and Audio
Application: Small or big animals

NIBP

The wider NIBP measurement range

Small& Big Animal
SYS 40~270mmHg
MEAN 20~230mmHg
DIA 10~210mmHg
Static Pressure range 0~300mmHg
NIBP measurement accuracy ±3mmHg

Over Pressure Protection
Hardware: 320-330mmHg
Software: 300mmHg

Oxygen Saturation (SpO2)
Measurement range:
SpO2: 0-100%
PR: 0-254bpm
Perfusion index: 0.05%-20%

Accuracy range
SpO2: 70%-100%
PR: 30-254bpm
Perfusion index: 0.05%-20%

Accuracy
SpO2: ±2 (70%-100%)
±3 (Under motion)
PR: ±3bpm
±5bpm (Under motion)

Temperature (TEMP)
Measurement range: 25- 45℃
Resolution: 0.1℃
Accuracy: 0.1℃

1.The smallest and exquisite handheld vital sign monitor in the worldwide. 2.Accurate measurement in 0.05% Low perfusion Index,the word leading production in the movement environment 3.Provide the parameter of PI( Perfusion Index 0.05%-20%) 4.Suitable for all kinds of animals 5.Easy operation by 3.5’’ color TFT 6.Multiple vital signs measurement parameters for collocation optional NIBP、Spo2、Temp NIBP、Temp Spo2、Temp 7.Up to 100 users ID switch 8.Two measurements mode:Spot、Monitoring 9.NIBP adopt SAWAA(Self-Adaptive-Waveform-Amplitude –Adjust)algorithm and SAFD(Self-Adaptive-Fast-Deflation)algorithm 10.Data storage capabilities, support for historical data view and trend chart back to see Under monitoring mode, can continuously record 48 hours of measurement data Under spot mode,100 users ID, each user can store 200sets data 11.Support audio and visual alarm,support to set alarm upper and lower limit values 12.Lithium ion battery power supply 13.Power Type: Lithium ion battery 14.Operation time: 8 hours for normal operation 15.Temperature: Operating: 0℃~45℃ 16.Starage/ Transportation: -20℃~65℃ 17.Humidity: Operating: 15% to 90% noncondensing 18.Storage: 10% to 95% noncondensing 19.Operating Altitude: Up to 5000 meters 20.Dimension :146mm*67mm*30mm Weight 250g Optional Charging dock4
